  • High resolution and high-quality PRECISION CORE printhead can achieve excellent printing performance and vivid bright colors.

  • Excluding the use of VOC (Volatile Organic Compounds) in the UV curable ink. The ink is enviromental friendly and no smell

  • With advanced automatic height detector which can detect the material thickness and find a good height position for the best quality printing.

  • Equipped with double negative pressure system for White and Color.

  • The printing platform is divided in 3 suction sections with adjustable vacuum.

  • The white ink catridge is with the automatic stiring and circulation system, wich avoids the clog of the white printhead.

Hybrid Jet 1804 UV

Model

Hybrid Jet 1804 UV

Print head/quantity

i3200-U1 2/4 heads

Ink type/colors

UV curable ink/CMYK, W, V.

Print wide/ media thickness

1.8m x 1.22m / 1-20 mm

Print modes

Clr+W+Clr/W+Clr/W+Clr+V/W*2+Clr/Clr+W/Clr*3

Printing speed

3sqm/h to 8sqm/s

Printing platform

- Mesh belt conveyor

- 3 stage (left,middle,right) suction platform

- Adjustable platform suction

Curing

Light curing liquid-cooled LED UV lamps

Materials

Glass, acrylic, PVC foam board, KT board, Wood, WPC, metal panels, ceramic tiles, MDF, Vinyl, PVC transparent, etc.

Photo file format

Tiff, jpeg, Postscript, eps, pdf

Cooling system

liquid type chiller

Ink supply system

Double negative pressure system with LCD monitor

Print interface

LAN

Software

SAiFlexi / MainTop / Riprint

Packing size/weight

Printer box: W 3.62m x L 1.13m x H 1.58m/820kg

(Includes printer and table stands disassembled)



Table stands box: W 2.12m x L 1.13m x H 0.59m

(Only if you require the table stands assembled, they come builded and folded)
